Featured Products - Contact us for more information
Telephone 704-527-4402 or Toll Free 888-CARY-VAC (888-227-9822) - Fax 704-525-4802 - Email: carysales@carymfg.com
| PRODUCT MODEL | PREVIOUS/OBSOLETE MODEL (PARTS Available) | Price | Phase | Voltage | Hz | HP | Max. Pressure in. H2O | Max. Vacuum in. H2O | Max. Flow: SCFM | Min. Flow: SCFM | Weight: lbs. (kg) |
|---|
| VFC080P-5T | | $392.41 | 1 | 115/230 | 60 | 0.1 | 19.5 | 18.7 | 19.5 | 0 | 13.3 (6.0) |
| VFC080A-2T | | $362.06 | 3 | 200-240 | 60 | 0.1 | 19.5 | 18.7 | 19.5 | 0 | 13.3 (6.0) |
| VFC080A-4W | | $362.06 | 3 | 400-480 | 60 | 0.1 | 19.5 | 18.7 | 19.5 | 0 | 13.3 (6.0) |
| VFC100A-7W | | $494.30 | 3 | 200-240/400-480 | 60 | 0.17 | 26.5 | 25 | 27 | 3.5 | 19 (8.6) |
| VFC100P-5T | | $570.18 | 1 | 115/230 | 60 | 0.17 | 27.5 | 26 | 27 | 3.5 | 19 (8.6) |
| VFC200A-7W | | $550.67 | 3 | 200-240/400-480 | 60 | 0.33 | 37 | 34 | 42 | 3.5 | 22(10) |
| VFC200P-5T | | $602.70 | 1 | 115/230 | 60 | 0.33 | 34 | 33 | 42 | 3.5 | 22(10) |
| VFC300A-5W | | $628.72 | 3 | 575 | 60 | 0.5 | 50 | 45 | 55 | 17 | 25.5(11.5) |
| VFC300A-7W | | $604.87 | 3 | 200-240/400-480 | 60 | 0.5 | 50 | 45 | 55 | 17 | 25.5(11.5) |
| VFC300P-5T | | $655.82 | 1 | 115/230 | 60 | 0.5 | 49 | 45 | 56 | 17 | 27(12.3) |
| VFC400P-5T | | $752.30 | 1 | 115/230 | 60 | 1 | 54.5 | 50 | 98 | 3.5 | 51(23) |
| VFZ401A-5W | VFC400A-5W | $711.10 | 3 | 575 | 60 | 1.4 | 58 | 52 | 89 | 7 | 46(20.1) |
| VFZ401A-7W | VFC400A-7W | $667.74 | 3 | 208-230/460 | 60 | 1.4 | 58 | 52 | 89 | 7 | 46(20.1) |
| VFB175P-5T | | $786.98 | 1 | 115/230 | 60 | 1.75 | 72 | 65 | 105 | 45 | 40(18.1) |
| VFC508P-2T | | $934.41 | 1 | 200/230 | 60 | 2.5 | 80 | 70 | 154 | 60 | 97.5(44) |
| VFZ501A-5W | VFC500A-5W | $870.45 | 3 | 575 | 60 | 2.7 | 80 | 80 | 135 | 45 | 77(35) |
| VFZ501A-7W | VFC500A-7W | $835.76 | 3 | 208-230/460 | 60 | 2.7 | 80 | 78 | 135 | 45 | 77(35) |
| VFZ601A-5W | VFC600A-5W | $1,350.66 | 3 | 575 | 60 | 5 | 134 | 95 | 173 | 56 | 108(49) |
| VFZ601A-7W | VFC600A-7W | $1,271.53 | 3 | 208-230/460 | 60 | 5 | 134 | 95 | 173 | 56 | 108(49) |
| VFZ701A-5W | VFC700A-5W | $1,818.95 | 3 | 575 | 60 | 6.7 | 105 | 99 | 217 | 87 | 134(60.8) |
| VFZ701A-7W | VFC700A-7W | $1,730.06 | 3 | 208-230/460 | 60 | 6.7 | 105 | 99 | 217 | 87 | 134(60.8) |
| VFZ801A-5W | VFC800A-5W | $3,115.42 | 3 | 575 | 60 | 10.7 | 115 | 108 | 379 | 132 | 211(95.7) |
| VFZ801A-7W | VFC800A-7W | $2,467.18 | 3 | 208-230/460 | 60 | 10.7 | 115 | 108 | 379 | 132 | 211(95.7) |
| VFZ901A-5W | VFC904A-5W | $3,524.08 | 3 | 575 | 60 | 14.7 | 100 | 85 | 574 | 191 | 259(117.5) |
| VFZ901A-7W | VFC804A-7W | $3,401.59 | 3 | 208-230/460 | 60 | 14.7 | 100 | 85 | 574 | 191 | 259(117.5) |
| VFB2000-7W | | $5,543.08 | 3 | 208-230/460 | 60 | 20 | 90 | 115 | 755 | 520 | 143(65) |
| PRODUCT MODEL | PRICE | VALVE SIZE | RING COMPRESSOR | Factory Set H2O (Max continous Operating Pressure) | ADJUSTMENT RANGE |
|---|
| VV3 | $140.92 | 1-1/2"NPT | VFC300 | 41" | 41"-29" |
| VV4 | $108.40 | 1-1/2"NPT | VFC400 | 48" | 48"-34" |
| VV5 | $127.91 | 1-1/2"NPT | VFC500 | 75" | 75"-51" |
| VV6 | $149.59 | 2" NPT | VFC600 | 86" | 86"-62" |
| VV7 | $149.59 | 2" NPT | VFC700 | 89" | 89"-64" |
| VV8 | $149.59 | 2" NPT | VFC800 | 101" | 101"-75" |
| VV9 | $274.25 | 2-1/2" NPT | VFC904/VFZ901 | 99" | 99"-75" |
| | | | | | |
| PV3 | $92.14 | 1-1/2"NPT | VFC300 | 45" | 45"-32" |
| PV4 | $93.22 | 1-1/2"NPT | VFC400/VFZ401 | 54" | 54"-38" |
| PV5 | $124.66 | 1-1/2"NPT | VFC500/VFZ501 | 77" | 77"-52" |
| PV6 | $126.83 | 2" NPT | VFC600/VFZ601 | 112" | 112"-73" |
| PV7 | $131.16 | 2" NPT | VFC700/VFZ701 | 117" | 117"-74" |
| PV8 | $117.07 | 2" NPT | VFC800/VFZ801 | 115" | 115"-75" |
| PV9 | $214.63 | 2-1/2" NPT | VFC904/VFZ901 | 125" | 125"-82 |
| PRODUCT MODEL | PRICE | RING COMPRESSORS |
|---|
| F-123 | $86.72 | VFC080-VFC300 |
| F-45 | $106.23 | VFC400-VFC508; VFZ401-VFZ501 |
| F-67 | $120.32 | VFZ601-VFZ701 |
| F-89 | $316.53 | VFZ801-VFZ901 |
| | | |
| C-123 | Call for Price | VFC080-VFC300 |
| C-45 | Call for Price | VFC400-VFC508; VFZ401-VFZ501 |
| C-67 | Call for Price | VFZ601-VFZ701 |
| C-89 | Call for Price | VFZ801-VFZ901 |
|
